Optimized for Delivery Vehicles and Commercial Start-stop Vehicles

• List of Battery Models

High-charge-acceptance, high-durability battery specially designed for delivery vehicles and commercial start-stop vehicles

In addition to adopting the HPL structure with a proven track record as an industry pioneer and high-density active material, the adoption of super quick charging¹ achieves the high charge acceptance² and high durability³ required for delivery vehicles and commercial start-stop vehicles.

• Improved durability through the use of high-density active material
• Adoption of *super quick charging¹
• Adoption of high-performance electrode plates
• Adoption of heavy-duty grid structure (D size / E size)
• Adoption of low-resistance separator*⁴
• Adoption of HPL structure

*¹ Super quick charging: Proprietary technology that increases the surface area by finely dispersing discharge particles (PbSO₄) of the negative active material, enabling efficient electrical conduction to the active material.
(Adopted only for D26, D31, and E41 sizes.)
*² Based on in-house test results for D26 size.
*³ Comparison of durability of active materials used in HG and HG-IS for E41 size (based on in-house test results).
*⁴ Adopted for D size and H size.

Super Quick Charging That Maximizes Limited Charging Opportunities

Charge Acceptance Performance Improved Compared with the HG Series

*Super quick charging¹, which has a proven track record even in passenger car batteries, has been adopted to the HG series.
In addition, low-resistance separators that suppress resistance during charge acceptance are also used (D size, G size, H size).
As a result, a large amount of charge can be accepted in a short period of time, achieving a significant improvement in charge acceptance performance compared with the HG series.

The Secret to Durability

Dedicated Design Optimized for Delivery Vehicles and Commercial Sart-stop Vehicles

By adopting high-density active material and optimizing the overall design, further improvements in durability have been achieved. This product has been refined into a more suitable solution for delivery vehicles and commercial start-stop vehicles, where frequent engine stop–start cycles tend to accelerate active material degradation.

Features of High-Performance Electrode Plates

List of Battery Models

Product Code	Nominal Voltage (V)	5HR Capacity (Ah)	External Dimensions (approx. mm)				Weight with liquid (approx. kg)	Replaceable type※
			Total height	Container height	Width	Length
HSG80D23R9B	12	52	225	204	173	232	16.5	55D23R, 60D23R, 65D23R, 70D23R, 75D23R, 80D23R
HSG80D23L9B								55D23L, 60D23L, 65D23L, 70D23L, 75D23L, 80D23L
HSG90D26R9B	12	55	225	204	173	260	19.0	55D26R, 65D26R, 75D26R, 80D26R, 85D26R, 90D26R
HSG90D26L9B								55D26L, 65D26L, 75D26L, 80D26L, 85D26L, 90D26L
HSG105D31R9B	12	64	225	204	173	306	22.0	75D31R, 85D31R, 95D31R, 100D31R, 105D31R
HSG105D31L9B								75D31L, 85D31L, 95D31L, 100D31L, 105D31L
HSG130E41R9B	12	92	234	213	176	410	28.5	95E41R, 100E41R, 105E41R, 110E41R, 115E41R, 120E41R, 130E41R
HSG130E41L9B								95E41L, 100E41L, 105E41L, 110E41L, 115E41L, 120E41L, 130E41L
HSG205G519B	12	144	257	213	222	508	45.5	145G51,155G51,165G51,180G51,195G51,205G51
HSG225H529B	12	176	270	220	278	521	62.0	190H52, 210H52, 225H52
